Counterline Free Standing Displays

•Roll under mobile hot cupboard.
•This unit maintains pre-heated cooked food at a regulated temperature.
•Includes midshelf and sliding doors as standard
•Supplied with 1500mm lead and 13amp plug top


IMHC9 30 942 x 693 x 569h
IMHC12 40 1242 x 693 x 569h
IMHC15 50 1542 x 693 x 569h

•These units can be rolled integrally into existing counter work or standalone as a central display. The standalone displays require additional panels. See finishes below.
•Avoid lifting heavy units into position and simply resolve condensing unit airflows.
•Accepts all Integrale, Da Vinci, and Manhattan standard width displays.

ICROLL2 2 x 1/1 815 x 670 x 830h
ICROLL3 3 x 1/1 1165 x 670 x 830h
ICROLL4 4 x 1/1 1515 x 670 x 830h
ICROLL5 5 x 1/1 1865 x 670 x 830h

•Wide versions are also available on request.
•Roll-ins for heated displays have ambient storage.
•Roll-ins for chilled displays have full internal airflow ducting with inlet and exhaust on operator’s side, except for 2/1 which has air inlet on customers side and exhaust on operators side.
•Customer side is Zintec as standard. Stainless or laminate fascia panel available as optional extra.
•Pre engineered rigid construction.
•All units mounted on four 100mm diameter castors, two lockable.

•These units can be rolled integrally into existing counter work or standalone as a central display. The standalone displays require additional panels.
•Avoid lifting heavy units into position and simply resolve condensing unit airflows.
•Accepts all Integrale, Da Vinci, and Manhattan standard width displays.
•Wide versions are also available on request.
•Roll-ins for heated displays have ambient storage.
•Customer side is Zintec as standard. Stainless or laminate fascia panel available as optional extra.
•Pre engineered rigid construction.
•All units mounted on four 100mm diameter castors, two lockable.
Heated base unit
IHROLL2 2 x 1/1 43 815 x 670 x 830h
IHROLL3 3 x 1/1 1165 x 670 x 830h
IHROLL4 4 x 1/1 1515 x 670 x 830h
IHROLL5 5 x 1/1 1865 x 670 x 830h

•Fully enclosed heated free-standing display for assisted service.
•This display maintains pre-heated cooked food at a regulated temperature.
•Ideal for hot rolls, pies, pasties, chicken portions etc.
•Illumination to all shelf levels.
•Castors included as standard which give an overall height of 1460 mm.
•Adjustable feet are available as an optional extra.
•Produce displayed on bright polished stainless steel shelf covers.
•Stainless steel shelf covers are removable for cleaning.
•Rear doors standard.
•Eye level electronic controller installed on operators side (GO) as standard.
•Square front glass version also available as optional extra.
•A wide range of optional extras are available.

New Experience Heated Self Help
•Open fronted heated display for self help service.
•This display maintains pre-heated cooked food at a regulated temperature.
•Perfect for hot rolls, pies, pasties, chicken portions etc.
•Illumination to all shelf levels.
•Produce displayed on bright polished stainless steel shelf covers removable for cleaning.
•Each shelf controlled individually. Controls located in drop-down fascia.
•Castors come as standard with this display.
•Fixed back as standard. Rear doors as optional extra.
•A wide range of optional extras are available.

•Open fronted heated free-standing display for self help service.
•This display maintains pre-heated cooked food at a regulated temperature.
•Ideal for hot rolls, pies, pasties, chicken portions etc.
•Illumination to all shelf levels.
•Castors included as standard which give an overall height of 1460 mm.
•Adjustable feet are available as an optional extra.
•Produce displayed on bright polished stainless steel shelf covers.
•Stainless steel shelf covers are removable for cleaning.
•Fixed back standard, rear doors optional.
•Eye level electronic controller installed on operators side (GO) as standard.
•The electric controller can be installed on customer side (GC) on request.
•Square front glass version also available as optional extra.
•A wide range of optional extras are available.

•Fully enclosed chilled free-standing food display for assisted service.
•This display maintains pre-chilled food at a regulated temperature.
•Ideal for sandwiches, filled rolls, dairy products, drinks etc.
•Three glass shelves with illumination to all shelf levels.
•Castors included as standard which give an overall height of 1460 mm.
•Adjustable feet are available as an optional extra.
•Integral fan blown refrigeration system.
•Rear doors standard.
•Eye level electronic controller installed on operators side (GO) as standard.
•Square front glass version also available as optional extra.
•A wide range of optional extras are available.

•A range of self contained illuminated chilled display units particularly suited to sandwich and cold drink sales with a choice between four or five glass shelves.
•This display maintains pre-chilled food at a regulated temperature.
•The range includes both narrow and wide-bodied versions, which accept either two or three standard sandwich packs across the width of each shelf.
•The displays incorporate their own base units and are supplied unfinished and ready to build into a shopfitted wall unit or front counter.
•The displays have an easily cleaned polished stainless steel interior with fully adjustable toughened glass shelves.
•Condensate is automatically evaporated eliminating the need for site drainage.
•Condensing unit mounted integrally. Designed for air in customer side and air out at rear. Nonstandard airflows are available.
•A wide range of optional extras are available.
•The overall size for the chilled and tall high capacity multidecks are the same. The taller units offer a larger display area.
•Overall sizes below are for standard units only and do not include any optional extras.


ICSLHCMD10 1029 x 555 x 1866h 150
ICSLHCMD12 1229 x 555 x 1866h 175
ICSLHCMD15 1529 x 555 x 1866h 200
ICSLHCMD18 1829 x 555 x 1866h 225
ICSLHCMD20 2029 x 555 x 1866h 250

•Open fronted chilled display for self help service.
•This display maintains pre-chilled food at a regulated temperature.
•Perfect for sandwiches, filled rolls, dairy products, drinks etc.
•Three glass shelves with illumination to all shelf levels.
•Integral fan blown refrigeration system.
•Electric defrost for safe 24 hour operation.
•Controls located in drop-down fascia.
•Castors come as standard with this display.
•Fixed back as standard. Rear doors as optional extra.
•A wide range of optional extras are available.

High Capacity Tall Multideck
A range of self contained illuminated chilled display units particularly suited to sandwich and cold drink sales with a choice between four or five glass shelves.
•This display maintains pre-chilled food at a regulated temperature.
•The range includes both narrow and wide-bodied versions, which accept either two or three standard sandwich packs across the width of each shelf.
•The displays incorporate their own base units and are supplied unfinished and ready to build into a shopfitted wall unit or front counter.
•The displays have an easily cleaned polished stainless steel interior with fully adjustable toughened glass shelves.
•Condensate is automatically evaporated eliminating the need for site drainage.
•Condensing unit mounted integrally. Designed for air in customer side and air out at rear. Nonstandard airflows are available.
•A wide range of optional extras are available.
•The overall size for the chilled and tall high capacity multidecks are the same. The taller units offer a larger display area.
•Overall sizes below are for standard units only and do not include any optional extras.


ICHCTMD10 1029 x 655 x 1866h 150
ICHCTMD12 1229 x 655 x 1866h 170
ICHCTMD15 1529 x 655 x 1866h 200
ICHCTMD18 1829 x 655 x 1866h 225
ICHCTMD20 2029 x 655 x 1866h 250

Chilled multideck
ICHCMD10 1029 x 655 x 1866h 150
ICHCMD12 1229 x 655 x 1866h 175
ICHCMD15 1529 x 655 x 1866h 200
ICHCMD18 1829 x 655 x 1866h 225
ICHCMD20 2029 x 655 x 1866h 250

Products available with rear doors
Unit
code Overall uncladded size
mm Weight
kg Wattage
kw
ICHCMD10DR 1029 x 655 x 1866h 150
ICHCMD12DR 1229 x 655 x 1866h 175
ICHCMD15DR 1529 x 655 x 1866h 200
ICHCMD18DR 2029 x 655 x 1866h 225
ICHCMD20DR 2029 x 655 x 1866h 250

•Fully enclosed ambient free-standing food display for assisted service.
•Ideal for confectionery, crisps, fruit etc.
•Three glass shelves with illumination to all shelf levels.
•Castors included as standard which give an overall height of 1460 mm.
•Adjustable feet are available as an optional extra.
•Open back as standard. Rear doors not available for this display.
•Square front glass version also available as optional extra.
•A wide range of optional extras are available.

Vision Ambient Self Help•
Open fronted ambient free-standing display for self help service.
•Ideal for confectionery, crisps, fruit etc.
•Three glass shelves with illumination to all shelf levels.
•Castors included as standard which give an overall height of 1460 mm.
•Adjustable feet are available as an optional extra.
•Open back as standard. Rear doors not available for this display.
•Square front glass version also available as optional extra.
•A wide range of optional extras are available.
