Gram Marine Range

Equipped with: Right hand hinged door with lock, dedicated locking handle, 5 stainless marine shelves, drycooling, rapid thaw, marine legs
Temperature range: -5/+12°C
Volume, gross: 660 ltr./23.3 cu.ft
Volume, net: 563 ltr./19.9 cu.ft
Exterior/Interior: Stainless/Stainless
W x D x H: 715 x 876 x 2155 mm
Weight, packed: 124 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 254 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 420 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 5 stainless marine shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 660 ltr./23.3 cu.ft.
Volume, net: 563 ltr./19.9 cu.ft
Exterior/Interior: Stainless/Stainless
W x D x H: 715 x 876 x 2155 mm
Weight, packed: 130 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 490 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 512 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 4 stainless marine shelves, drycooling, rapid thaw, marine legs
Temperature range: -5/+12°C
Volume, gross: 600 ltr./21.2 cu.ft.
Volume, net: 506 ltr./17.9 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 756 x 2005 mm
Weight, packed: 117 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 254 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 420 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 4 stainless marine shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 600 ltr./21.2 cu.ft.
Volume, net: 506 ltr./17.9 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 756 x 2005 mm
Weight, packed: 122 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 490 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 512 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 5 stainless marine shelves, marine legs
Temperature range: -5/+12°C
Volume, gross: 660 ltr./23.3 cu.ft.
Volume, net: 563 ltr./19.9 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 756 x 2155 mm
Weight, packed: 123 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 254 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 420 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 5 stainless marine shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 660 ltr./23.3 cu.ft.
Volume, net: 563 ltr./19.9 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 756 x 2155 mm
Weight, packed: 130 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 490 Watt
Connection: 230 V, 60 Hz
Connection load: 512 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 4 stainless marine shelves, drycooling, rapid thaw, marine legs
Temperature range: -5/+12°C
Volume, gross: 425 ltr./15.0 cu.ft.
Volume, net: 388 ltr./13.7 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 620 x 731 x 2110 mm
Weight, packed: 114 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 226 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 260 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 4 stainless marine shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 425 ltr./15.0 cu.ft.
Volume, net: 388 ltr./13.7 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 620 x 731 x 2110 mm
Weight, packed: 118 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 365 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 421 Watt

Equipped with: Right hand hinged glass door with lock, dedicated locking handle, automatic door closing, 4 stainless marine shelves, marine legs
Temperature range: +2/+12°C
Volume, gross: 425 ltr./15.0 cu.ft.
Volume, net: 388 ltr./13.7 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 620 x 731 x 2110 mm
Weight, packed: 124 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134a
Ref. capacity at -10°C: 426 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 379 Watt

Equipped with: Right hand hinged glass door with lock, automatic door closing, dedicated locking handle, 4 stainless marine shelves, marine legs
Temperature range: -5/-25°C
Volume, gross: 425 ltr./15.0 cu.ft.
Volume, net: 388 ltr./13.7 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 620 x 731 x 2110 mm
Weight, packed: 127 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 685 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 681 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 4 stainless marine shelves, drycooling, rapid thaw, marine legs
Temperature range: -5/+12°C
Volume, gross: 625 ltr.
Volume, net: 571 ltr.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 731 x 2110 mm
Weight, packed: 121 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 254 Watt
Connection: 230 V, 60 Hz
Connection load: 360 Watt

Equipped with: Right hand hinged door with lock, dedicated locking handle, 4 stainless marine shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 625 ltr./22.1 cu.ft.
Volume, net: 571 ltr./20.2 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 731 x 2110 mm
Weight, packed: 128 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 490 Watt
Connection: 230 V, 60 Hz
Connection load: 512 Watt

Equipped with: Right hand hinged glass door with lock, automatic door closing, dedicated locking handle, 4 stainless marine shelves, marine legs
Temperature range: +2/+12°C
Volume, gross: 625 ltr./22.1 cu.ft.
Volume, net: 571 ltr./20.2 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 731 x 2110 mm
Weight, packed: 131 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134a
Ref. capacity at -10°C: 426 Watt
Connection: 230 V, 60 Hz
Connection load: 429 Watt

Equipped with: Right hand hinged glass door with lock, automatic door closing, dedicated locking handle, 4 stainless marine shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 625 ltr./22.1 cu.ft
Volume, net: 571 ltr./20.2 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 835 x 731 x 2110 mm
Weight, packed: 138 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 685 Watt
Connection: 230 V, 60 Hz
Connection load: 735 Watt

Equipped with: Stainless steel solid top, 2 door sections each with 2 stainless shelves, marine legs
Temperature range: +2/12°C
Volume, gross: 345 ltr./12.2 cu.ft.
Volume, net: 255 ltr./9 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 1289 x 700 x 905 mm
Weight, packed: 124 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 314 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 262 Watt

Equipped with: Stainless steel solid top, 2 door sections each with 2 stainless shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 345 ltr./12.2 cu.ft.
Volume, net: 255 ltr./9 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 1289 x 700 x 905 mm
Weight packed: 124 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 714 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 668 Watt

Equipped with: Stainless steel solid top, 3 door sections each with 2 stainless shelves, marine legs
Temperature range: +2/+12°C
Volume, gross: 506 ltr./17.9 cu.ft.
Volume, net: 397 ltr./14 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 1726 x 700 x 905 mm
Weight packed: 158 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 400 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 333 Watt

Stainless steel solid top, 3 door sections each with 2 stainless shelves, marine legs

Equipped with: Stainless steel solid top, 3 door sections each with 2 stainless shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 506 ltr./17.9 cu.ft.
Volume, net: 397 ltr./14 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 1726 x 700 x 905 mm
Weight packed: 158 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 404 a
Ref. capacity at -25°C: 714 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 675 Watt

Stainless steel solid top, 4 door sections each with 2 stainless shelves, marine legs

Equipped with: Stainless steel solid top, 4 door sections each with 2 stainless shelves, marine legs
Temperature range: +2/+12°C
Volume, gross: 668 ltr./23.6 cu.ft.
Volume, net: 539 ltr./19 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 2163 x 700 x 905 mm
Weight packed: 189 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 487 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 385 Watt

Stainless steel solid top, 4 door sections each with 2 stainless shelves, marine legs

Equipped with: Stainless steel solid top, 4 door sections each with 2 stainless shelves, marine legs
Temperature range: -25/-5°C
Volume, gross: 668 ltr./23.6 cu.ft.
Volume, net: 539 ltr./19 cu.ft.
Exterior/Interior: Stainless/Stainless
W x D x H: 2163 x 700 x 905 mm
Weight packed: 189 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 404 a
Ref. capacity at -25°C: 830 Watt
Connection: 230 V, 50 and 60 Hz
Connection load: 772 Watt

Equipped with: Right hand hinged reversible door with lock, 2 stainless marine shelves, 1 stainless bottom shelf
Temperature range: +2/+12°C
Volume, gross: 125 ltr./4.4 cu.ft.
Volume, net: 104 ltr./3.7 cu.ft.
Exterior/Interior: Stainless/ABS lining in grey
W x D x H: 595 x 640 x 830 mm
Weight packed: 46 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 155 Watt
Connection: 230 V, 60 Hz
Connection load: 93 Watt

Equipped with: Right hand hinged reversible door with lock, 2 stainless marine shelves, 1 bottom stainless shelf
Temperature range: -22/-5°C
Volume, gross: 125 ltr./4.4 cu.ft.
Volume, net: 104 ltr./3,7 cu.ft.
Exterior/Interior: Stainless/ABS lining in grey
W x D x H: 595 x 640 x 830 mm
Weight packed: 46 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -25°C: 171 Watt
Connection: 230 V, 60 Hz
Connection load: 178 Watt
System: No Frost with automatic reevaporation

Equipped with: Right hand hinged reversible door with lock, 5 stainless marine shelves, 1 stainless bottom shelf, marine legs
Temperature range: +2/+12°C
Volume, gross: 346 ltr./12.3 cu.ft.
Volume, net: 312 ltr./11.1 cu.ft.
Exterior/Interior: Stainless/ABS lining in grey
W x D x H: 595 x 640 x 1905 mm
Weight packed: 75 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 205 Watt
Connection: 230 V, 60 Hz
Connection load: 149 Watt

Equipped with: Right hand hinged reversible door with lock, 5 stainless marine shelves, 1 stainless bottom shelf, marine legs
Temperature range: -22/-5°C
Volume, gross: 346 ltr./12.3 cu.ft.
Volume, net: 312 ltr./11.1 cu.ft.
Exterior/Interior: Stainless/ABS lining in grey
W x D x H: 595 x 640 x 1905 mm
Weight packed: 78 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -25°C: 194 Watt
Connection: 230 V, 60 Hz
Connection load: 208 Watt
System: No Frost with automatic reevaporation

Equipped with: Right hand hinged reversible door with lock, 5 stainless marine shelves, marine legs
Temperature range: +2/+12°C
Volume, gross: 583 ltr./20.7 cu.ft.
Volume, net: 513 ltr./18.2 cu.ft.
Exterior/Interior: Stainless/ABS lining in grey
W x D x H: 695 x 868 x 2005 mm
Weight packed: 110 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 371 Watt
Connection: 230 V, 60 Hz
Connection load: 349 Watt

Equipped with: Right hand hinged reversible door with lock, 5 stainless marine shleves, marine legs
Temperature range: -25/-5°C
Volume, gross: 583 ltr./20.7 cu.ft.
Volume, net: 513 ltr./18.2 cu.ft.
Exterior/Interior: Stainless/ABS lining in grey
W x D x H: 695 x 868 x 2005 mm
Weight packed: 113 kg
Insulation: 60 mm (cyclopentane)
Refrigerant: R 404 A
Ref. capacity at -25°C: 528 Watt
Connection: 230 V, 60 Hz
Connection load: 571 Watt
System: No Frost with automatic reevaporation

Equipped with: Right hand hinged glass door with lock, internal lighting, 2 stainless marine shelves, 1 stainless bottom shelf
Temperature range: +2/+12°C
Volume, gross: 125 ltr./4.4 cu.ft.
Volume, net: 104 ltr./3.7 cu.ft.
Exterior/Interior: Stainless/ABS lining in grey
W x D x H: 595 x 640 x 830 mm
Weight packed: 52 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 256 Watt
Connection: 230 V, 60 Hz
Connection load: 187 Watt

Equipped with: Right hand hinged glass door with lock, internal lighting, 2 stainless marine shelves, 1 stainless bottom shelf
Temperature range: -22/-5°C
Volume, gross: 125 ltr./4.4 cu.ft.
Volume, net: 104 ltr./3.7 cu.ft.
Exterior/Interior: Stainless/ABS lining in white
W x D x H: 595 x 640 x 830 mm
Weight packed: 55 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -25°C: 194 Watt
Connection: 230 V, 60 Hz
Connection load: 211 Watt
System: No Frost with automatic reevaporation

Equipped with: Right hand hinged glass door with lock, internal lighting, 5 stainless marine shelves, 1 stainless bottom shelf, marine legs
Temperature range: +2/+12°C
Volume, gross: 346 ltr./12.3 cu.ft.
Volume, net: 312 ltr./11.1 cu.ft.
Exterior/Interior: Stainless/ABS lining in white
W x D x H: 595 x 640 x 1905 mm
Weight packed: 84 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -10°C: 329 Watt
Connection: 230 V, 60 Hz
Connection load: 226 Watt

Equipped with: Right hand hinged glass door with lock, internal lighting, 5 stainless marine shelves, 1 stainless bottom shelf, marine legs
Temperature range: -22/-5°C
Volume, gross: 346 ltr./12.3 cu.ft.
Volume, net: 312 ltr./11.1 cu.ft.
Exterior/Interior: Stainless/ABS lining in white
W x D x H: 595 x 640 x 1905 mm
Weight packed: 95 kg
Insulation: 50 mm (cyclopentane)
Refrigerant: R 134 a
Ref. capacity at -25°C: 251 Watt
Connection: 230 V, 60 Hz
Connection load: 294 Watt
System: No Frost with automatic reevaporation
